Decorative Lever with Square Rose, Baldwin DEC-TSR

$75.00 $60.00

Vendor: Baldwin
SKU: BAL-DEC-TSR-0SBP
Type:


FREE GROUND SHIPPING ON ALL ORDERS ABOVE $250.00!
Baldwin DEC-TSR, Classic Leverset with Square Rosette

The Decorative Lever with Square Rose is lovely--a great addition to traditional homes. Choose from 7 finishes including polished nickel, satin nickel and polished brass. The Decorative square rose leverset is easy to install and will fit most predrilled doors. It is available as a keyed entry as well as a privacy, passage, or dummy.

Features of the Baldwin Decorative Square Rose Lever:

  • 2-1/8" cross bore and 1" edge bore for latch
  • Latch Bolt: 1/2"
  • Strike: square corner
  • Keyed entry features the Baldwin 5-pin tumbler C keyway.
  • Tested to exceed ANSI/BHMA Grade 2 Security.
  • Warranty: 25 year finish warranty and a limited lifetime mechanical warranty.

Specifications of the Decorative Square Rose Lever Set:

  • Lever Length: 4-1/4"
  • Projection:2-3/4"
  • Keyed Entry Projection: 2-9/16"
  • Rose Length: 2-19/32" Square
  • Door Thickness: 1-3/8" - 2" standard with optional thick door kit for 2" - 2-1/2".
  • Backset: Adjustable for 2-3/4" or 2-3/8"
  • Latchbolt: 1/2"

When Selecting a Function:

  • Half Dummy: A surfaced mounted, non-working lever. Non-locking and non-latching trim for one side of door. This inactive pull is usually used to match trim.
  • Full Dummy: Non-working levers. Non-locking and non-latching trim for both sides of door. These inactive pulls are usually used to match trim.
  • Passage (hall or closet): Latches but does not lock. The latch is activated by turning the either of the two levers.
  • Privacy (bedroom or bathroom): Latches and can be locked. Can be locked from the inside with a push-button.
  • Keyed Entry: Use when a keyed lock is needed. An ANSI/BHMA A156.2 Grade 2 security lock that is operated by a key from the exterior and a turnbutton on the lever from the interior. Complete set - 2 levers, 2 roses, 2 keys, door latch and strike plate.

Sold Individually. Interior roses and Half Dummy roses have exposed screws.
