The Federal Leverset with Square Rose is a very sophisticated looking leverset. The combination of the sleek yet classic lever paired with the more modern look of the square rose makes it a popular choice for designers everywhere. This leverset is easy to install. It will fit 1-3/8 inch to 2-1/2 inch thick doors with 2-3/8 inch or 2-3/4 inch backsets. The Federal Lever is available in passage, privacy and dummy functions. It is also available as a grade 2 keyed entry function. Choose from one of the 6 beautiful finishes.

Features of the Federal Leverset:

• 2-1/8" cross bore and 1" edge bore for latch
• Latch Bolt: 1/2"
• Strike: square corner
• Keyed entry features the Baldwin 5-pin tumbler C keyway.
• Tested to exceed ANSI/BHMA Grade 2 Security.
• Warranty: 25 year finish warranty and a limited lifetime mechanical warranty.

Specifications of the Federal Lever with Square Rosette:

• Lever Length: 4-1/4"
• Projection: 2-1/2"
• Keyed Entry Projection: 2-9/16"
• Rose Length: 2-19/32" square
• Door Thickness: 1-3/8" - 2" standard with optional thick door kit for 2" - 2-1/2".
• Backset: Adjustable for 2-3/4" or 2-3/8"
• Latchbolt: 1/2"

When Selecting a Function:

• Half Dummy: A surfaced mounted, non-working lever. Non-locking and non-latching trim for one side of door. This inactive pull is usually used to match trim.
• Full Dummy: Non-working levers. Non-locking and non-latching trim for both sides of door. These inactive pulls are usually used to match trim.
• Passage (hall or closet): Latches but does not lock. The latch is activated by turning the either of the two levers.
• Privacy (bedroom or bathroom): Latches and can be locked. Can be locked from the inside with a push-button.
• Keyed Entry: Use when a keyed lock is needed. An ANSI/BHMA A156.2 Grade 2 security lock that is operated by a key from the exterior and a turnbutton on the lever from the interior. Complete set - 2 levers, 2 roses, 2 keys, door latch and strike plate.

Sold Individually. Interior roses and Half Dummy roses have exposed screws.
