The Madrid Knurled Lever with Square Rose features a satin brass rosette an stem and a matte black knurled handle. This combination of finishes it stunning, eye-catching, and modern--the 3 biggest desires of interior designers when doing a home remodel. The Explore Hardware Knurled Madrid Lever is one or our most comprehensive door levers. It is easy to install; and maymore more important easy to order. All you kneed to know is which function you need and the backset of the door. The Black and Satin Brass Madrid Lever will fit most predrill doors.

Features of the Black and Satin Brass Madrid Lever:

• Fits standard door cut outs (2-1/8" pre-drilled doors).
• Solid brass lever and trim rose.
• Sold as complete set.
• Easy to install.

Specifications of the Knurled Leverset with Square Rose:

• Material: Brass
• Finish: Satin Brass with Matte Black
• Lever Length: 4.96" (126mm)
• Lever Diameter: 0.87" (22.2mm)
• Lever Projection: 2.47" (62.9mm)
• Rose Length: 2.36" (59.9mm) square
• Rose Projection: 0.39" (10mm)
• Door Thickness: 1-3/8" to 1-3/4"
• Backset: 2-3/8" or 2-3/4"
• Handing: non-handed
• AHI Madrid Dimensions Diagram (PDF)

Available Functions:

• Single Dummy: No door latch. Door lever on one side of the door. Visible surface mounting screws. Package Includes: 1 lever, 1 rose, and mounting screws.
• Double Dummy: No door latch. Door levers on both sides of the door. Visible surface mounting screws on interior and exterior. Package Includes: 2 levers, 2 roses, and mounting screws.
• Passage (Hall or Closet): For doors that don't need locking. Latch operates from either side of door. Visible mounting screws on interior. Package Includes: 2 levers, 2 roses, door latch, strike plate, dust box, faceplate, spindle, and mounting screws.
• Privacy (Bedroom or Bathroom): For doors that could need privacy locking. Latch operates from either side. Privacy pin on interior rose engages privacy; emergency release hole is on exterior rose. Visible mounting screws on interior. Package Includes: 2 levers, 2 roses, privacy button, door latch, strike plate, dust box, faceplate, spindle, and mounting screws.

Sold Individually
