Solid Brass 8 Inch Surface Bolt, Deltana 8SB

$76.24 $58.84

Vendor: Deltana
SKU: DEL-8SB-CR003
Type:


FREE GROUND SHIPPING ON ALL ORDERS ABOVE $250.00!
Deltana 8SB, Heavy Duty Solid Brass 8" Surface Slide Bolt

Decorative door bolts made of Heavy Duty Solid Brass. It is available in an array of different finishes. The guides are held in place with a unique ball bearing system that eliminates scratches on the barrel of the bolt, prevents rattling of the bolt, holds the bolt in any position, and ensures a smooth sliding action. Each 8 inch surface bolt is supplied with 3 strikes: universal, mortise, and angle strike with matching solid brass phillip's head screws.

Deltana 8SB 8 Inch Surface Bolt Specifications

Also Available: Deltana 6SB 6" Surface Bolt - Deltana 12SB 12" Surface Bolt - Deltana 18SB 18" Surface Bolt - Deltana 24SB 24" Surface Bolt

Specifications for the Deltana 8SB 8 Inch Surface Bolt:

  • Material: Solid Brass
  • Bolt Length: 8"
  • Bolt Throw: 1-1/16"
  • Bolt Width: 5/8" Diameter Half Round Rod
  • Width of Guides: 1-1/2"
  • Knob Diameter: 1-1/4"
  • Rod Resistance: 109 lbs
  • Strikes: Includes 3 Strikes
  • Deltana 8SB 8" Surface Bolts Dimensions (PDF)

No matter which finish you choose for the outside, it will still be solid brass material inside.
